Product Features

Digital Twin Technology — Virtual five-axis machine tool operation simulation, error warnings during simulated machining, and synchronized machining between simulation and physical equipment.

Five-Axis Simultaneous Machining — Supports 5-axis simultaneous machining, 3+2 positional machining, and 5-axis tool center point control (RTCP).

Automatic Tool Change System — Supports automatic tool change for 6 or more tools, with a tool change time of ≤4 s, improving machining efficiency.

Automatic Tool Setting — Integrates an automatic tool setting function to improve machining accuracy and tool setting efficiency.

Multiple Machining Modes — Supports homing, automatic machining, manual, handwheel, MDI, resume machining from a breakpoint, and other operating modes.

CAM Software Compatibility — Compatible with mainstream CAM software such as MasterCAM, SolidCAM, and CAXA.

Comprehensive NC Code Support — Supports a wide range of G-code and M-code instructions and is compatible with standard CNC programs.

Specifications

Software Configuration

Category	Name	Version / Requirement
Operating System	Windows	64-bit Windows 10 or later
Word Processing Software	Microsoft Office	2016 or later
CAM Software	MasterCAM	2025
CAM Software	SolidCAM	2025
CAM Software	CAXA	2025
Digital Twin Machining System	HuiMaiTech	V2.0

Recommended Hardware Configuration

Equipment	Specification	Equipment	Specification
X/Y/Z Axis Travel	350 × 130 × 200 mm	Movement Accuracy	≈0.03 mm
B-Axis Rotation Angle	-100° to +100°	Repeat Positioning Accuracy	PS = 0.02 mm
C-Axis Rotation Angle	n × 360°	Rapid Feed Rate	6 m/min
Worktable Size	Ø120 mm	Cutting Feed Rate	1–5 m/min
Worktable Load Capacity	≥10 kg	Tool Magazine Capacity	6 tools  (standard configuration)
T-Slot Size	8 × 11 × 4 mm	Tool Change Time	≤4 s
Spindle Taper	ISO20 tool holder taper	Total Equipment Power	7.5 kW
Spindle Speed	20,000 rpm	Overall Dimensions	1100 × 1200 × 2000 mm
Main Motor Power	2 kW	Power Supply Requirement	220 V, 16 A
Cooling Method	Water cooling and air cooling	Air Supply Requirement	6 kg/cm²

Application Scenarios

Education and Training

· Theory and practical training in CNC multi-axis machining

· Digital twin technology application training

· CAM programming and process planning training

Industrial Applications

· Virtual verification of product machining processes

· Five-axis machine tool operation skills training

· Machining process simulation and error warning

Skills Training

· Computer-aided programming training

· Virtual-physical synchronized five-axis machining training

· Product inspection and quality control training

FAQ

Q: Which machining modes does the platform support?

A: The platform supports 5-axis simultaneous machining, 3+2 positional machining, and 5-axis tool center point control (RTCP), as well as homing mode, automatic machining mode, manual mode, handwheel mode, MDI, handwheel machining mode, resume machining from a breakpoint, and other machining modes.

Q: How does the digital twin function help ensure machining safety?

A: The platform provides virtual five-axis machine tool operation simulation and pre-error alerts for simulated machining. Before actual machining, full-process simulation verification can be completed in a virtual environment to identify programming errors and collision risks in a timely manner, helping ensure safe machining on the physical machine tool.

Q: Does the platform support automatic tool change and tool setting?

A: Yes. The platform supports automatic tool change for 6 or more tools, with a tool change time of ≤4 s, and integrates an automatic tool setting function, significantly improving machining efficiency and consistency of machining accuracy.
