Product Features

8K High-Resolution Printing System

10.3-inch 8K monochrome LCD screen with 7680 x 4320 resolution for fine-detail printing; 8x anti-aliasing slicing support; 0.05-0.15 mm layer thickness for precision training tasks.

Fast Photopolymer Resin Curing

405 nm integrated light source with 95% light uniformity; 1-4 seconds per layer printing speed; 3D nano release technology to reduce release resistance and improve printing stability.

Stable Mechanical Structure

Dual linear guide rails and ball screw on the Z-axis for stable positioning; fully enclosed housing to reduce ambient light interference; built-in air filtration system for classroom and laboratory training environments.

Smart Connectivity and Workflow Support

Cloud platform support for model library sharing, 3D slicing, and G-code generation; USB offline printing and WiFi printing options; intelligent material feeding with automatic resin refill and resin recovery functions.

Technical Specifications

Basic Information

Printing Parameters

Display and Light Source

Structure and Functions

Application Scenarios

Teaching and Training

• Advanced manufacturing courses: supports teaching on photopolymer curing principles, LCD printing technology, and additive manufacturing workflows.
• 3D printing practical training: helps learners complete the workflow from model preparation to resin printing.
• Precision manufacturing training: demonstrates high-precision printing applications at 0.05 mm layer thickness level.

Industrial Design

• Rapid prototyping: supports quick verification of product appearance and structural design.
• Precision part production: suitable for training projects related to precision molds, dental models, jewelry casting patterns, and detailed component fabrication.
• Cultural and creative product development: supports the production of models with complex surfaces and fine textures.

Research and Laboratory Practice

• Material research: supports testing and verification of photopolymer resin formulations and material performance.
• Process parameter optimization: supports experiments on how layer thickness and exposure time affect forming quality.
• Reverse engineering practice: can be used with 3D scanning equipment for data acquisition, model reconstruction, and resin printing validation.

FAQ

Q: What level of printing accuracy can the CT-005PRO support?

A: The CT-005PRO uses a 10.3-inch 8K monochrome LCD screen with 7680 x 4320 resolution and adjustable layer thickness from 0.05 to 0.15 mm. Combined with a 405 nm integrated light source with 95% light uniformity, the platform supports precision resin printing tasks for teaching, prototyping, and applied training.

Q: Is the platform suitable for beginners?

A: Yes. The platform includes a 5-inch full-color touch screen and supports both USB offline printing and WiFi printing. The cloud platform provides 3D slicing and G-code generation functions, while the intelligent material feeding system supports automatic resin refill and remaining resin recovery. These functions help learners become familiar with the resin printing workflow step by step.

Q: How does the platform support a safer training environment?

A: The CT-005PRO uses a fully enclosed housing to reduce ambient light interference and limit resin odor exposure during training. It also includes a built-in air filtration system and related TVOC testing documentation. OTA online upgrades are supported for software and system updates.
